Rear spring, approximately 15mm lowering, GSX1300R

【HYPERPRO Hyperpro 22051711 Rear Spring, Lowdown Approx. 15mm, GSX1300R Suspension】
■Rear Spring
This lowdown spring, unique to Hyperpro, lowers the vehicle height by changing the spring rate and adjusting the oil level, without significantly altering the free length of the spring.
Enjoy the smooth ride of a constant rising rate spring that softly absorbs shocks and maintains its performance deeply into the stroke.
Compatible models
SUZUKI GSX1300R '08-'17
SUZUKI GSX1300R(ABS) '08-'17
Specifications
Lowdown: approx. 15mm
Spring material number: 468
Preload adjustment: 10mm
Sag value: 26mm
Compression adjustment: 8 clicks out
Rebound adjustment: 12 clicks out.
*When using the side stand, park on a flat surface in first gear. (The bike will stand more upright than with the stock setup due to the lowdown.)
*After installation, the bike's balance will change significantly. Always adjust the front and rear settings before riding.
*Lowdown parts are considered designated parts, so no structural modification procedures are required.
*For lowdowns of 30mm or more, a short side stand may be required depending on the vehicle's condition. For models with preload adjustment, please adjust the settings while ensuring the side stand can be used at the desired lowdown amount.
*The image is for illustration purposes only, and the design and specifications of the products listed may change without notice. Thank you for your understanding.
