Compact All-LED Rear Combination Lamp, Without Back Buzzer, Type B (Left), 24V

【KOITO Koito LEDRCL-24LK Compact All-LED Rear Combination Lamp, No Back Buzzer, Type B (Left), 24V, Auxiliary Lamp for Trucks and Trailers, Koito】
Smart & Stylish
Revolutionary All-in-One
All functions condensed into a compact unit
Achieves long life with Koito's LED technology
Hazard power-saving specifications available (power consumption reduced by 92% compared to conventional models)
【UN ECE certified product】

Depending on the vehicle model year and the combination of LED rear combination lamps, installation may not be possible.
Please check the compatible vehicle models below.
Please note that this compatibility table is reference information based on Koito Manufacturing's own research and does not guarantee compatibility.
Therefore, after installing it on the vehicle, please check its operation and ensure that it does not violate any automobile-related laws and regulations such as safety standards.
Specifications:
・Type: B type (left)
・Rating: 24V
・Tail: 0.4W
・Stop: 4.4W
・Turn: 24.0W
・Back: 3.7W
Compatible with:
・Isuzu / Elf, Mazda / Titan (representative examples)
Precautions:
* When purchasing, please check the mounting pitch of the light fixture currently installed.
* For hazard power-saving specifications, please use a left and right set, and be sure to use the optional hazard power-saving connection harness.
If not used, the hazard power-saving function will not operate correctly.
● This product is exclusively for 24V automobiles. Do not use it for vehicles other than 24V automobiles.
Furthermore, we are not responsible for malfunctions or other issues that occur when used for purposes other than the specified applicable uses.
● The hole diameter and connection connector differ between Type A and Type B, so please check before installation.
● The back buzzer emits sound from the bottom, so do not block the opening.
The sound may become inaudible.
● This LED rear combination lamp, repair parts (brackets), and optional parts are intended for vehicles sold after 2010.
● If installed on a trailer (towed vehicle), it is not covered by the warranty.
● After installing this LED rear combination lamp, please make sure that the wire breakage detection function (equipped in the vehicle) as stipulated by safety standards operates correctly.
If the wire breakage detection function does not operate correctly, it violates regulations and cannot be installed.
● In case of damage, the entire assembly must be replaced.
● The inner surface of the lens may temporarily fog up due to driving in the rain or car washing.
This is the same phenomenon as windows fogging up in the rain, and there is no functional problem.
● If the outermost edge of the reflective part of the reflex reflector built into the rear combination lamp extends beyond 400mm (Koito recommends 385mm) from the outermost edge of the automobile,
install the included reflex reflector within 400mm from the outermost edge of the automobile / the upper edge of the reflex reflector within 900mm from the ground, and the lower edge at least 250mm from the ground.
● To ensure this product is always used and installed in the best condition, please be sure to thoroughly read the "Instruction Manual" and "Precautions for Use" included with the product,
understand their contents, and use the product correctly.
● This product is exclusively for automobiles. Do not use it for anything other than automobiles.
Furthermore, we are not responsible for malfunctions or other issues that occur when used for purposes other than the specified applicable uses.
● Please use it in a way that does not violate automobile-related laws and regulations such as safety standards.
● Specifications and production are subject to change or discontinuation without prior notice, so please be aware.
* The actual specifications may differ from left to right.
* The image is for illustration purposes only, and the design and specifications of the products shown are subject to change without notice. Please understand.
