Truck All-LED Rear Combination Lamp, 3-Gang Sequential Turn Signal, Right, Clear, 24V, 1 pc.

【KOITO KOITO LEDRCL-24RSCD Truck All-LED Rear Combination Lamp, 3-Gang Type, Sequential Turn, Right, Clear, 24V, 1 pc. Koito】
Smart & Stylish
New clear inner lens version added to the lineup.
Achieves a clear appearance when not lit.
Expanded options in addition to the red version (red inner lens).
【UN ECE certified product】

● Can also be installed on light-duty trucks (24V vehicles).
● By adopting LEDs (0.3 seconds faster instantaneous lighting compared to incandescent bulbs),
following vehicles can identify the truck 7m earlier when driving at 80km/h, reducing the risk of rear-end collisions.
★ Regarding the integration to 21W specification (excluding Mitsubishi Fuso)
The 3-gang type currently offers 25W and 21W specifications, but as of 'June 1, 2021', it will be integrated into the 21W turn specification.
This is to improve the robustness against detection methods (thresholds) for turn signal bulb outages, which vary by manufacturer, and electrically controlled systems, by integrating it into a lamp with the same power consumption as incandescent bulbs (21W).
We kindly ask for your understanding and cooperation.
(1) Applicable products: 3-gang type (normal turn/sequential turn specifications) * Excludes Yabusame, 2-gang type, and Kabuki design
(2) Applicable manufacturers: Hino Motors / Isuzu Motors / UD Trucks * Excludes Mitsubishi Fuso
(3) Start date: June 1, 2021 ~
* Please use the 25W specification for Mitsubishi Fuso vehicles.
* The 25W specification will continue to be sold for repair and replacement.
【Precautions for repair and replacement】

For repair and replacement (one side) of vehicles equipped with the 25W specification, be sure to install the 25W specification.
If a different specification product is installed, the turn signal flashing speed will not match, leading to non-compliance with regulations.
Installation may not be possible depending on the combination of the vehicle model year and the LED rear combination lamp.
Please check the applicable vehicle models and necessary options from the following.
Please note that this compatibility table is reference information based on Koito Manufacturing Co., Ltd.'s own research and does not guarantee compatibility.
Therefore, after installing it on the vehicle, perform an operation check and use it in a manner that does not violate automobile-related laws and regulations such as safety standards.
Specifications:
・Category: Sequential Turn
・Type: Right
・Color: Clear
・Rated: 24V
・Tail: 2.0W
・Stop: 7.6W
・Turn: 25.5W
・Back: 3.2W
・Vinyl tube color (Right/Left): Red/Yellow
・Quantity: 1 pc.
Precautions:
● These LED rear combination lamps and optional parts are intended for vehicles sold in 2010 or later.
● Warranty is void if installed on trailers (towed vehicles).
● After installing this LED rear combination lamp, always check that the filament break detection function (built into the vehicle) as stipulated by safety standards operates correctly.
If the filament break detection function does not operate correctly, it will be a violation of regulations and cannot be used.
● Before purchasing, please check the installation space. If there is not enough space, it cannot be installed.
(Please check the lamp dimensions on this page or in the "Smart Truck Lamp Series" catalog.)
● If a warning canceller is used, power saving may be compromised.
● For classifications of large, medium, and small vehicles, please check the vehicle inspection certificate provided with the vehicle.
● In case of damage, ASSY replacement is required.
● Even if the lamp is in normal condition, the inside of the lens may temporarily fog up during rainy weather or car washing.
This is the same phenomenon as window glass fogging up in the rain, and there are no functional problems.
● To ensure the best performance and installation of this product, please be sure to read the "Instruction Manual" and "Precautions for Use" included with the product carefully and use it correctly after understanding the contents.
● This product is exclusively for automobiles. Do not use it for anything other than automobiles.
Furthermore, we are not responsible for any malfunctions that occur when used for purposes other than the specified applicable uses.
● Please use in a manner that does not violate automobile-related laws and regulations such as safety standards.
● Specifications and production are subject to change or discontinuation without prior notice. Please be aware of this in advance.
* The actual specifications may differ from the left and right sides.
* The image is for illustration purposes only, and the design and specifications of the products shown are subject to change without prior notice. Please understand.
