LED-compatible universal IC turn signal relay (12V 3-pin) CF13 30×30×35mm

【MADMAX MM19-0276-2 LED Compatible Universal IC Turn Signal Relay (12V 3-pin) CF13 30×30×35mm Blinker Indicator Parts MADMAX】
■Product Description
This is an IC turn signal relay, CF13 3P specification.
It properly controls the blinking frequency of the turn signals.
It prevents the hyper-flashing phenomenon that occurs when turn signals are changed to LED.
It supports a wide range of bulbs with an allowable current of 0.02A to 20A.
It is useful not only for LED conversion but also as a repair part.
The relay makes no operating sound.
The terminals are marked B, L, and E.
B: Connect to the 12V battery side (positive)
L: Connect to the turn signal (bulb) side
E: Ground (negative)
With high versatility, it is compatible with various 3-pin relay specification vehicles, whether two-wheeled or four-wheeled.
Please check the pin arrangement in advance.

■Specifications
Size: Approx. 30 x 30 x 35mm (excluding terminals)
Terminals: 10 x 6mm

■Notes
*Images are for illustration purposes only. Includes products with different sizes and colors.
*Product design and specifications are subject to change without notice. Please be aware of this.
*Not suitable for battery-less vehicles.
*As no waterproofing has been applied, waterproofing may be required depending on the installation location.
*Please note that colors may vary depending on the shooting environment.
*Processing may be required for installation.
*As these are imported products, there may be some minor scratches from transportation.
*Installation of parts should be performed by a qualified mechanic or a mechanic with specialized knowledge.
*Please note that we are not responsible for any malfunctions that occur during installation. Thank you for your understanding.
