Rear Shock MX456 White Spring Specification CBX400/550F

[PMC YSS Rear Shock MX456 White Spring Specification CBX400/550F 117-35111203]
・This is a full-spec model equipped with a full-adjustable mechanism, connecting the all-billet body and reservoir tank with a mesh hose, allowing free adjustment of the reservoir tank's mounting position.
・It is equipped with adjustment mechanisms for low-speed compression damping (1 system), rebound damping (1 system), spring preload, and ride height.
・The large-capacity reservoir tank prevents cavitation and increases oil volume, providing excellent heat dissipation.
・Designed with racing use in mind, this large-capacity, high-rigidity big body overcomes even extreme, unrealistic conditions.
Specifications:
・Type: MX456
・Color: White Spring Specification
・Spring: ID56 180N/mm L150
・Piston diameter: φ45
・Spindle rod: φ16
・Mount: Bearing
Compatible models:
・HONDA CBX400/550F
Important notes on images:
*This is the White Spring specification.
*Photos are representative examples of the model.
*Specifications such as color, shape, and set contents may differ.
*Please check before purchasing.
*The image is for illustration purposes only, and the design and specifications of the products shown may change without notice. Please understand.
