Rear Suspension S-MAX155 MX362-TRC

【PMC 117-3512009 Rear Suspension S-MAX155 MX362-TRC Motorcycle Parts Suspension 】
■Product Description
This full-spec model features a full-adjustable mechanism, connecting an all-billet body and a reserve tank with a mesh hose, allowing the reserve tank's mounting position to be freely changed.
It is equipped with adjustment mechanisms for low-speed compression damping (1 system), rebound damping (1 system), spring preload, and ride height.
The large-capacity reserve tank prevents cavitation and increases oil volume, providing high heat dissipation.
The body is ideally suited for compact vehicle designs, offering rigidity that firmly supports the foot area.
It is compatible with a wide range of uses, from street to racing.

■Compatible Models
YAMAHA S-MAX155 '13-'17

■Specifications
Spring: ID46 60-90N/mm L145
Ride height adjustment: 320(315-325)
Piston outer diameter: φ45
Shaft outer diameter: φ16
Mount: Bearing

■Notes
*Images are for illustration purposes only. They may include products with different sizes and colors.
*Product designs and specifications are subject to change without notice. Thank you for your understanding.
