Rear Suspension GTR150/RS150/Sonic150 MX366-TRW

【PMC 117-4311022 Rear Suspension GTR150/RS150/Sonic150 MX366-TRW Motorcycle Parts - Undercarriage Suspension】
■Product Description
This top-of-the-line racing-spec model features an all-billet body and a remote reservoir connected by a mesh hose, allowing for flexible mounting of the reservoir. It is equipped with a full adjustable mechanism.
It features high/low-speed compression damping (2-way), rebound damping (1-way), spring preload, and ride height adjustment mechanisms.
The large-capacity reservoir prevents cavitation and increases oil volume, providing excellent heat dissipation.
The body is perfectly suited for compact vehicle designs, offering robust support for the vehicle's undercarriage.
It is suitable for a wide range of applications, from street use to racing.

■Compatible Models
HONDA GTR150 '16- / RS150 '15- / SONIC150 '15-

■Specifications
Spring: ID46 230-350N/mm L120
Shock overall length: 235mm
Piston outer diameter: φ36mm
Shaft outer diameter: φ16mm

■Other Notes
*No ride height adjustment function

■Important Notes
*Images are for illustration purposes only. Includes products with different sizes and colors.
*Product designs and specifications may change without prior notice. Please be aware.
