Rear Suspension NSF100 MX366-TRW

[PMC 117-43119100 Rear Suspension NSF100 MX366-TRW Motorcycle Parts Undercarriage Suspension]

■Product Description
This top-end racing-spec model features an all-billet body and a reserve tank connected by a mesh hose, allowing for flexible mounting of the reserve tank. It is equipped with full adjustable mechanisms.
It features high/low speed compression damping (2 systems), rebound damping (1 system), spring preload, and ride height adjustment mechanisms.
The large-capacity reserve tank prevents cavitation and increases oil capacity for high heat dissipation.
The body is ideally suited for compact vehicle designs, providing the rigidity needed to firmly support the vehicle's undercarriage.
It is suitable for a wide range of uses, from street to racing.

■Compatible Models
HONDA NSF100 '88-'07

■Specifications
Spring: ID46 200N/mm L100
Shock Total Length: 220-230(220)mm
Piston Outer Diameter: φ36mm
Shaft Outer Diameter: φ16mm

■Notes
*Images are for illustration purposes only. Includes products with different sizes and colors.
*Product design and specifications are subject to change without notice. Thank you for your understanding.
