Rear suspension ZX-10R MX456-TRW with HPA

【PMC 117-4510335R Rear Suspension ZX-10R MX456-TRW with HPA Motorcycle Parts Undercarriage Suspension】
■Product Description
This top-end racing-spec model features an all-billet body connected to a reservoir tank via a mesh hose, allowing for flexible mounting of the reservoir tank. It is equipped with a fully adjustable mechanism.
It delivers high performance with all adjustment mechanisms, including two compression damping systems, one rebound damping system, hydraulic spring preload, and ride height.
The large-capacity reservoir tank prevents cavitation and increases oil capacity, providing excellent heat dissipation.
Designed with racing use in mind, this large-capacity, high-rigidity big body overcomes extremely harsh conditions.

■Compatible Models
KAWASAKI ZX-10R '16-

■Specifications
Spring: ID56 110N/mm L130
Shock Total Length: 310 (305-315) mm
Piston Outer Diameter: φ45mm
Shaft Outer Diameter: φ16mm

■Notes
*Images are for illustration purposes only. Products with different sizes and colors may be included.
*Product design and specifications may change without prior notice. Please be aware of this.
