Rear Suspension MT-09 MX456-TRW with HPA

【PMC 117-4512300R Rear Suspension MT-09 MX456-TRW with HPA Motorcycle Parts Footpeg Suspension 】
■Product Description
This top-end model boasts racing specifications, featuring an all-billet body and a reserve tank connected by a mesh hose, allowing for flexible mounting of the reserve tank. It's equipped with a fully adjustable mechanism.
It features adjustments for high/low-speed compression damping (2 systems), rebound damping (1 system), spring preload, and ride height.
The large-capacity reserve tank prevents cavitation and increases oil volume, providing excellent heat dissipation.
Designed with racing use in mind, this large-capacity, high-rigidity big body overcomes even the most extreme and unrealistic conditions.
Includes hydraulic preload adjuster

■Compatible Models
YAMAHA MT-09 '13-'16

■Specifications
Spring: ID56 100N/mm L150
Shock Total Length: 330 (325-335)
Piston Outer Diameter: φ45
Shaft Outer Diameter: φ16
Mount: Bearing

■Notes
*Images are for illustration purposes only. They may include products with different sizes or colors.
*Product design and specifications are subject to change without notice. Please understand.
